CTE C750 TG ARGB Full Tower Chassis
CTE Form Factor
Designed by Thermaltake
The CTE Form Factor Designed by Thermaltake, stands for Centralized Thermal Efficiency, and is focused around providing high level thermal performance to critical components. The design utilizes a 90-degree rotation of the motherboard providing more efficient airflow pathways.
Since the CPU location has been moved much closer to the front panel and the graphics card moved closer towards the rear panel, independent cold air induction is given for thermal dissipation of the CPU and graphics card respectively. This overall approach has allowed CTE to provide better and more efficient intake airflow through the placement of main components and cooling, as well as optimization to heat extraction from the system.
The image is for reference only.
The CTE C750 is the flagship model of the CTE form factor series, which utilizes Centralized Thermal Efficiency and focuses on providing high levels of thermal performance to critical components.
The design utilizes a 90-degree rotation of the motherboard providing more efficient airflow pathways.
The video is for reference only.
Move Critical Heat Sources (CPU And Graphic Cards) Closer Towards Cool Air
Since the CPU location of the CTE C750 has been moved much closer to the front panel and the graphics card moved closer towards the rear panel, independent cold air induction is given for thermal dissipation of the CPU and graphics card respectively.
The video is for reference only.
Active Cooling for More Efficient Intake Airflow
This overall approach has allowed CTE C750 to provide better and more efficient intake airflow through the placement of main components and cooling, as well as optimization to heat extraction from the system.
The video is for reference only.
Delivering Cooling Performance Beyond Imagination!
The CTE C750 TG ARGB is a specially designed E-ATX full tower chassis from the new CTE form factor series, and is designed to provide high levels of thermal performance to critical components. It comes with three pre-installed 140mm CT140 ARGB fans and can support up to 420mm AIO radiators at the front, rear and motherboard side of the chassis. Its dual-chamber design allows users to showcase key components and provides ample space for superior cooling solutions, with the ability to accommodate up to 14 fans inside the case thanks to the front, bottom and rear fan brackets, and top and M/B side fan vent. It also features many fine details such as rotating PCI-E slots, removable filters, a pump and reservoir bracket and Velcro straps for easy cable management. Whether you are looking for a case for custom liquid cooling or a dual AIO configuration, the CTE C750 TG ARGB is a high-end showcase chassis that allows you to imagine outside the box.
Maximum radiator support - up to 360mm/420mm radiators in multiple locations
Our CTE C750 TG ARGB offers excellent cooling support for custom liquid cooling enthusiasts, there are various support locations and enough space to arrange your own configurations. Up to 5 radiators fit into our CTE C750 at the same time (three 360mm and two 240mm radiators), providing incredible radiator support.
For AIO compatibility , up to 420mm/360mm radiators can be installed on the front, rear and motherboard side, giving PC enthusiasts endless possibilities for their ideal setup.
The image is for reference only.
All your dream cooling components can fit!
The CTE C750 Full Tower Chassis has enormous fan and cooler installation capacity: up to fourteen 140mm fans and 360mm/420mm AIO coolers at various positions. Moreover, equipped fan brackets at the front, bottom, and rear side ensure easy installation of all your desired cooling components.
The image is for reference only.
Blow your world away with three pre-installed 140mm CT140 ARGB fans
CTE C750 TG ARGB Full Tower Chassis features three 140mm ARGB PWM Fans at the front, top and rear. The LED lighting effects can be manipulated with motherboard supported software. Users can create an amazing RGB lighting show while enjoying the utmost cooling performance at the same time.
The image is for reference only.
Unify your fans with your build!
Thermaltake launches brand-new CT series fans, allowing users to choose from black or white, RGB or non-RGB, to match whatever color scheme you have.
Display it your way
Rotational PCI-E slots give you the option to display your graphics card either horizontally or vertically, creating plenty of flexible space for your system. If you choose to install your graphics card vertically, there is an extra riser cable bracket allows both 90 degree or 180 degree riser cable installation.
The image is for reference only.
We’ve tested everything, so you don’t have to
At Thermaltake, we always stress test our products under harsh conditions to ensure product quality. The CTE C750 TG ARGB Full Tower Chassis products were tested at 100% full load for 30 minutes, with the most high-end CPU, GPU, and motherboard at the time of test, while paring with a consumer-style setup, allowing us to test how the chassis performs under real-world situations.
Test System
- Chassis：CTE C750 TG ARGB Snow
- Motherboard：ASUS ROG MAXIMUS Z790 APEX
- CPU：Intel® Core™ i9-13900K Processor (TDP 253W)
- GPU：ASUS ROG Strix GeForce RTX® 4090 OC 24GB GDDR6X
- RAM：TOUGHRAM XG RGB DDR5 32G (16G x 2)
- SSD：Seagate SSD 120G
- PSU：Toughpower GF3 1200W - TT Premium Edition
- CPU Cooler：TH420 ARGB Sync Snow Edition AIO Liquid Cooler
- FANs：
AIO: CT140 ARGB Fan x 3
Chassis: CT140 ARGB Fan x 11
(Front x 3 , Top x 2 , Rear x 3, Bottom x 3 )
CPU & GPU Thermal Stress Test
CTE C750 TG ARGB
Massive Airflow & Incredible Performance
Thermal images taken during thermal testing. Thanks to its CTE form factor design and three pre-installed CT140 ARGB Sync PC Cooling Fans, we were able to ensure that the CTE C750 TG ARGB has massive airflow, guaranteeing amazing cooling performance that keeps the internal temperature low and stable while using the most high-end components.
Idle
Full Load
Opportunities For High-End Expansion
CTE C750 TG ARGB has excellent expandability, allowing you to build the most high-end system you can dream of. It can support up to an E-ATX (12”x13”) motherboard, a CPU cooler with a maximum height of 190mm, VGA clearance up to 420mm in length without a radiator, a power supply with a length of up to 220mm, and up to twelve 2.5” SSD or seven 3.5” HDD. Optimized for excellent cooling capabilities, the CTE C750 TG ARGB can accommodate up to three 140mm/120mm fans at the front, rear, bottom and motherboard side, up to two 200mm fans at the front and rear, up to two 140mm/120mm fans on top, and AIO radiators of up to 420/360mm at the front, rear and M/B side, providing endless possibilities for PC lovers to build their desired system.
- Dimensions
- Fan Capacity
- All-in-One Compatibility
- Custom Liquid Cooling Compatibility
-
CPU Cooler
Max height 190mm
-
Motherboard
6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX),
12” x 9.6” (ATX), 12” x 13” (E-ATX)
-
PSU
Max length
220mm
-
VGA
Length limitation
370mm (with radiator)
420mm (without radiator)
Perfect Dust Protection
There are fine removable filters at the top, front, bottom, rear and right side of the chassis to provide excellent protection against dust, and they are easily removable for cleaning.
Everything you need is located in one place
Four USB 3.0 ports, one USB 3.2 Gen 2 Type-C, and HD Audio ports are placed on the top panel to grant direct access when needed.
Radiator Support List
All-in-One Compatibility List
| 120mm | 240mm | 360mm | 140mm | 280mm | 420mm | |
|---|---|---|---|---|---|---|
| Front | ● | ● | ● | ● | ● | ● |
| Top | ● | ● | - | ● | - | - |
| Right-Side | ● | ● | ● | ● | ● | ● |
| Rear | ● | ● | ● | ● | ● | ● |
| Bottom | - | - | - | - | - | - |
Custom Liquid Cooling Compatibility List
| 120mm | 240mm | 360mm | 140mm | 280mm | ||
|---|---|---|---|---|---|---|
| Front | ● | ● | ● | ● | ● | |
| Top | ● | ● | - | ● | - | |
| Right-Side | ● | ● | ● | ● | ● | |
| Rear | ● | ● | ● | ● | ● | |
| Bottom | ● | ● | ● | ● | ● |
Fan Support List
Fan Support List
| 120mm | 140mm | 200mm | |
|---|---|---|---|
| Front | 3 | 3 | 2 |
| Top | 2 | 2 | - |
| Right-Side | 3 | 3 | - |
| Rear | 3 | 3 | 2 |
| Bottom | 3 | 3 | - |
Sync with Motherboard RGB Software
Designed to synchronize with ASUS Aura Sync, GIGABYTE RGB Fusion, MSI Mystic Light Sync, and ASRock Polychrome. It supports motherboards with a 5V addressable RGB header, allowing you to control the lights directly from the software mentioned above without installing any extra lighting software or controllers. For more details, please visit ASUS, GIGABYTE, MSI, and ASRock official websites.
-
Aura Addressable Header
ASUS -
Digital Pin Header
GIGABYTE -
JRAINBOW Header
MSI -
Addressable RGB LED Header
ASRock
| Category | Caution |
|---|---|
| Chassis, ARGB Fan, ARGB AIO |
|
| RGB Memory, VGA Waterblock, Distro Plate |
|
| P/N | CA-1X6-00F1WN-01 |
|---|---|
| Serie | CTE |
| Modello CASE | Full Tower |
| DIMENSIONI (H x W x D) | 565.2 x 327 x 599.2 mm (22.25 x 12.87 x 23.59 inch) |
| PESO NETTO | 16.7 kg / 36.82 lbs. |
| PANNELLI LATERALI | 4mm Tempered Glass x 2 |
| COLORE | Black |
| MATERIALE | SPCC / ABS |
| SISTEMA DI RAFFREDDAMENTO | Front(intake): 140 x 140 x 25 mm CT140 ARGB fan (1500rpm, 30.5 dBA) x 1 Top(exhaust): 140 x 140 x 25 mm CT140 ARGB fan (1500rpm, 30.5 dBA) x 1 Rear(intake): 140 x 140 x 25 mm CT140 ARGB fan (1500rpm, 30.5 dBA) x 1 |
| ALLOGGIAMENTI DRIVE | 7 x 3.5” or 12 x 2.5” |
| SLOT DI ESPANSIONE | 7 |
| SCHEDE MADRI | 6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX), 12” x 13” (E-ATX) |
| I/O PORT | USB 3.2 (Gen 2) Type-C x 1, USB 3.0 x 4, HD Audio x 1 |
| ALIMENTATORE | Standard PS2 PSU (optional) |
| VENTOLE SUPPORTATE | Front: 3 x 120mm, 2 x 120mm, 1 x 120mm 3 x 140mm, 2 x 140mm, 1 x 140mm 2 x 200mm, 1 x 200mm Top: 2 x 120mm, 1 x 120mm 2 x 140mm, 1 x 140mm Right (M/B Side): 3 x 120mm, 2 x 120mm, 1 x 120mm 3 x 140mm, 2 x 140mm, 1 x 140mm Rear: 3 x 120mm, 2 x 120mm, 1 x 120mm 3 x 140mm, 2 x 140mm, 1 x 140mm 2 x 200mm, 1 x 200mm Bottom: 3 x 120mm, 2 x 120mm, 1 x 120mm 3 x 140mm, 2 x 140mm, 1 x 140mm |
| RADIATORI SUPPORTATI | Front: 1 x 360mm, 1 x 240mm, 1 x 120mm 1 x 420mm(AIO only), 1 x 280mm, 1 x 140mm Top: 1 x 240mm, 1 x 120mm 1 x 140mm Right (M/B Side): 1 x 360mm, 1 x 240mm, 1 x 120mm 1 x 420mm(AIO only), 1 x 280mm, 1 x 140mm Rear: 1 x 360mm, 1 x 240mm, 1 x 120mm 1 x 420mm(AIO only), 1 x 280mm, 1 x 140mm Bottom: 1 x 360mm, 1 x 240mm, 1 x 120mm 1 x 280mm, 1 x 140mm |
| AUTORIZZAZIONE | CPU cooler max height: 190mm VGA max length: 370mm (With radiator) 420mm (Without radiator) PSU max length: 220mm |
User Manual
- File Name
- Description
- Size
- Version
- Release Date
-
CTE C750 TG ARGB Manual
- 2023-03-20
